For reference only, photos / specs may not reflect actual content.

Axial Flow Fan
Sunon 80x80x25mm AC115V
Model SF11580AT PN: 1082 Series
Sunon 80x80x25mm AC220V~AC240V
Model SF23080AT PN: 2082 Series
FNAC-xxx

Link(s):

Options:

#

P/N #

 V Amp Bearing RPM CFM dBA Note
1 SF11580AT 1082HSL.GN 115V 0.12A / 0.10A Sleeve Bearing 2300~2750 17~21 29~33 xxx
2 SF11580AT 1082HBL.GN 115V 0.12A / 0.10A Ball Bearing 2450~2900 18~22 30~34.5 xxx
3 SF23080AT 2082HSL.GN 220V / 240V 0.07A / 0.07A Sleeve Bearing 2300~2750 17~21 29~33 xxx
4 SF23080AT 2082HBL.GN 220V / 240V 0.07A / 0.07A Ball Bearing 2450~2900 18~22 30~34.5 xxx
5 xxx xxx xxx xxx xxx xxx xxx xxx

Note:

  • Pictures may not reflect actual items.

  • Specifications may change without notice, subject to manufacturers.
