Meets ASTM B633 SC1, Type III specifications for
electroplating of > 5um = .002" thickness. This material is well
suited for non-corrosion enviroments. |
 |
PART
NUMBER |
THREAD
LENGTH
In. (mm) |
ANCHOR DIA.
In. (mm) &
DRILL BIT
DIA. In. (mm) |
OVERALL
LENGTH
In. (mm) |
MAX. THICKNESS
OF MATERIALS
TO BE FASTENED
In. (mm) |
QTY/WT
PER BOX
lbs. |
QTY/WT
PER MASTER
CARTON
lbs. |
CWS-3830
CWS-3836
CWS-3850 |
1-5/8 (66.7)
2-3/8 (73.0)
3-5/8 (88.9) |
3/8" - 16
3/8" - 16
3/8" - 16 |
3 (76.2)
3-3/4 (95.3)
5 (127.0) |
5/8 (15.9)
1-3/8 (34.9)
2-5/8 (66.7) |
50/ 5.3
50/ 5.9
50/ 7.3 |
400/ 42
300/ 35
300/ 44 |
CWS-1236
CWS-1242
CWS-1244
CWS-1254
CWS-1270 |
2-1/8 (54.0)
2-5/8 (66.7)
2-7/8 (73.0)
3-7/8 (98.4)
5-3/8 (136.5) |
1/2" - 13
1/2" - 13
1/2" - 13
1/2" - 13
1/2" - 13 |
3-3/4 (95.3)
4-1/4 (108.0)
4-1/2 (114.3)
5-1/2 (139.7)
7 (177.8) |
3/4 (19.1)
1-1/4 (31.8)
1-1/2 (38.1)
2-1/2 (63.5)
4 (101.6) |
25/ 5.7
25/ 6.7
25/ 7.0
25/ 8.0
25/ 9.2 |
150/ 34
150/ 41
150/ 40
150/ 49
150/ 55 |
CWS-5850
CWS-5860
CWS-5870
CWS-5884 |
3-3/16 (81.0)
4-3/16 (106.4)
5-3/16 (131.8)
5-3/4 (146.0) |
5/8" - 11
5/8" - 11
5/8" - 11
5/8" - 11 |
5 (127.0)
6 (152.4)
7 (177.8)
8-1/2 (215.9) |
1-1/8 (28.6)
2-1/8 (54.0)
3-1/8 (79.4)
4-5/8 (117.5) |
10/ 4.7
10/ 5.4
10/ 6.2
10/ 8.0 |
100/ 48
50/ 28
30/ 19
30/ 25 |
