Ethernet Switch
Cisco Gigabit Switch Catalyst 3560 Series
24x 10/100Base-TX + PoE & 2x SFP Enhanced Image
P/N: WS-C3560-24PS-E (1U Rack Mountable)
SW-CS-C3560-24PS-E

Product Overview


The Cisco® Catalyst® 3560 Series is a line of fixed-configuration, enterprise-class switches that include IEEE 802.3af and Cisco prestandard Power over Ethernet (PoE) functionality in Fast Ethernet and Gigabit Ethernet configurations. The Cisco Catalyst 3560 is an ideal access layer switch for small enterprise LAN access or branch-office environments, combining both 10/100/1000 and PoE configurations for maximum productivity and investment protection while enabling the deployment of new applications such as IP telephony, wireless access, video surveillance, building management systems, and remote video kiosks. Customers can deploy networkwide intelligent services-such as advanced quality of service (QoS), rate limiting, access control lists (ACLs), multicast management, and high-performance IP routing-while maintaining the simplicity of traditional LAN switching. Available for the Cisco Catalyst 3560 Series at no charge, the Cisco Network Assistant is a centralized management application that simplifies the administration tasks for Cisco switches, routers, and wireless access points. Cisco Network Assistant provides configuration wizards that greatly simplify the implementation of converged networks and intelligent network services.

Main Features

  • Manufacturer: Cisco Systems, Inc
  • Manufacturer Part Number: WS-C3560-24PS-E-RF
  • Manufacturer Website Address: www.cisco.com
  • Brand Name: Cisco
  • Product Line: Catalyst
  • Product Series: 3560
  • Product Model: 3560-24PS
  • Product Name: Catalyst 3560-24PS PoE Switch
  • Marketing Information: The Cisco Catalyst 3560-24PS PoE Switch is a fixed-configuration, enterprise-class switch that includes IEEE 802.3af and Cisco prestandard Power over Ethernet (PoE) functionality in Fast Ethernet and Gigabit Ethernet configurations. The Cisco Catalyst 3560-24PS PoE Switch is an ideal access layer switch for small enterprise LAN access or branch-office environments, combining both 10/100/1000 and PoE configurations for maximum productivity and investment protection while enabling the deployment of new applications such as IP telephony, wireless access, video surveillance, building management systems, and remote video kiosks. Customers can deploy networkwide intelligent services-such as advanced quality of service (QoS), rate limiting, access control lists (ACLs), multicast management, and high-performance IP routing-while maintaining the simplicity of traditional LAN switching. Available for the Cisco Catalyst 3560-24PS PoE Switch at no charge, the Cisco Network Assistant is a centralized management application that simplifies the administration tasks for Cisco switches, routers, and wireless access points. Cisco Network Assistant provides configuration wizards that greatly simplify the implementation of converged networks and intelligent network services.
  • Product Type: Layer 3 Switch
  • Number of Ports: 24
  • Fast Ethernet Port: Yes
  • Number of Expansion Slots: 2
  • Expansion Slots: (2 Total) SFP
  • Manageable: Yes
  • Standard Memory: 128 MB
  • Input Voltage: 110 V AC, 220 V AC
  • Input Voltage Range: 100 V AC to 240 V AC
  • Form Factor: Rack-mountable, Wall Mountable, Desktop
  • Dimensions: 1.73" Height x 17.50" Width x 11.80" Depth
  • Weight (Approximate): 11.30 lb
  • Package Contents: Catalyst 3560 3560-24PS PoE Switch , Catalyst 3560 Switch Getting Started Guide , Regulatory Compliance and Safety Information for the Catalyst 3560 Switch , Product registration card , AC power cord , One RJ-45-to-DB-9 adapter cable , Mounting kit containing:
      , Four rubber feet for mounting the switch on a table , Two 19-inch rack-mounting brackets , Six Phillips flat-head screws for attaching the brackets to the switch , Four Phillips machine screws for attaching the brackets to a rack , One cable guide and one black Phillips machine screw for attaching the cable guide to one of the mounting brackets , One redundant power system (RPS) connector cover , Two Phillips pan-head screws , Four Phillips truss-head screws
  • Standard Warranty: Not Applicable
General Information
  • Manufacturer: Cisco Systems, Inc
  • Manufacturer Part Number: WS-C3560-24PS-E-RF
  • Manufacturer Website Address: www.cisco.com
  • Brand Name: Cisco
  • Product Line: Catalyst
  • Product Series: 3560
  • Product Model: 3560-24PS
  • Product Name: Catalyst 3560-24PS PoE Switch
  • Marketing Information:
    The Cisco Catalyst 3560-24PS PoE Switch is a fixed-configuration, enterprise-class switch that includes IEEE 802.3af and Cisco prestandard Power over Ethernet (PoE) functionality in Fast Ethernet and Gigabit Ethernet configurations. The Cisco Catalyst 3560-24PS PoE Switch is an ideal access layer switch for small enterprise LAN access or branch-office environments, combining both 10/100/1000 and PoE configurations for maximum productivity and investment protection while enabling the deployment of new applications such as IP telephony, wireless access, video surveillance, building management systems, and remote video kiosks. Customers can deploy networkwide intelligent services-such as advanced quality of service (QoS), rate limiting, access control lists (ACLs), multicast management, and high-performance IP routing-while maintaining the simplicity of traditional LAN switching. Available for the Cisco Catalyst 3560-24PS PoE Switch at no charge, the Cisco Network Assistant is a centralized management application that simplifies the administration tasks for Cisco switches, routers, and wireless access points. Cisco Network Assistant provides configuration wizards that greatly simplify the implementation of converged networks and intelligent network services.
  • Product Type: Layer 3 Switch

Interfaces / Ports:

  • Number of Ports: 24

  • Fast Ethernet Port: Yes

Media & Performance:

  • Connectivity Media:
     Category 3, 4, 5 UTP 10Base-T
    Category 5 UTP 100Base-TX

  • Performance:
     32Gbps Forwarding Bandwidth
    6.5Mpps Forwarding Rate For 64-byte Packet

I/O Expansions:

  • Number of Expansion Slots: 2

  • Expansion Slots:(2 Total) SFP

Network & Communication:

  • Layer Support: Layer 2, Layer 3, Layer 4

Management & Protocols:

  • Manageable: Yes

  • Management:

    • Cisco Express Setup

    • Cisco Network Assistant Software

    • IEEE 802.1p CoS Prioritization

    • Cisco IOS

    • IEEE 802.1Q VLAN

    • Switching Database Manager

    • Cisco Group Management Protocol server

    • Remote SPAN (RSPAN)

    • RMON groups (history, statistics, alarms, and events)

    • Web-based management interface

    • CiscoWorks network-management software

    • SNMP v1, v2c, and v3

    • Telnet

    • CLI

    • CiscoWorks LAN Management Solution

Memory:

  • Standard Memory: 128 MB

  • Memory Technology: DRAM

  • Flash Memory: 16 MB

Power Description:

  • Input Voltage: 110 V AC / 220 V AC

  • Input Voltage Range: 100V AC to 240V AC

  • Power Source: Power Supply

  • Redundant Power Supply: Yes

Physical Characteristics:

  • Form Factor:

  • Rack-Mountable
    Wall Mountable
    Desktop

  • Dimensions: 1.73" Height x 17.50" Width x 11.80" Depth

  • Weight (Approximate: 11.30 lb

Shipping Information:

  • Shipping Weight: 15.0 lb

Miscellaneous:
  • Package Contents:
    • Catalyst 3560 3560-24PS PoE Switch
    • Catalyst 3560 Switch Getting Started Guide
    • Regulatory Compliance and Safety Information for the Catalyst 3560 Switch
    • Product registration card
    • AC power cord
    • One RJ-45-to-DB-9 adapter cable
    • Mounting kit containing:
      • Four rubber feet for mounting the switch on a table
      • Two 19-inch rack-mounting brackets
      • Six Phillips flat-head screws for attaching the brackets to the switch
      • Four Phillips machine screws for attaching the brackets to a rack
      • One cable guide and one black Phillips machine screw for attaching the cable guide to one of the mounting brackets
      • One redundant power system (RPS) connector cover
      • Two Phillips pan-head screws
      • Four Phillips truss-head screws

  • Additional Information:

    • Refurbished

    • No Returns

    • IEEE 802.3af and Cisco prestandard Power over Ethernet

    • IP Services license (formerly EMI) installed

    • Bandwidth aggregation up to 8 Gbps through Cisco Gigabit EtherChannel technology and up to 800 Mbps through Cisco Fast EtherChannel technology
