Ethernet Switch
16-port 10/100Mbps
Airlink ASW316

Equip your small office with the power of a high-speed network! The ASW316 16-port 10/100 Switch efficiently handles high bandwidth between multiple computers, making file-sharing and data transfer faster than ever. Able to accommodate 100Mbps of data transfer, the ASW316 can even extend the power of fast Ethernet throughout your network!


  • Compliant with the IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX

  • 16 x 10/100Mbps Auto-Negotiation, Auto MDI/MDI-X ports

  • Green Ethernet Technology effectively reduces power consumption

  • Support up to 8K MAC address

  • Up to 1.25M bits packet buffer

  • Supports Store & Forward architecture and performs forwarding and filtering

  • IEEE802.3x flow control for Full-duplex

  • Back Pressure function for Half-duplex operation

  • Supports to handle up to 1552 bytes packet

  • LED indicators for simple diagnostics and management

  • Build-in universal power


Standards IEEE 802.3 10BaseT, IEEE 802.3u 100BaseTX, IEEE 802.3x Flow Control
Ports 16 x 10/100Mbps Auto-MDI/MDI-X RJ45 connector
Data Transfer Rate 10/100Mbps (Half-Duplex)
20/200Mbps (Full-Duplex)
Forwarding Method Store and forward
MAC Address 8K
Buffer Memory 1.25M Bits
LED Indicators Per Unit: Power
Link/ACT (Per Port)
  Solid Green: Link
  Blinking Green: Activity
Speed (Per Port)
Access Method CSMA/CD
Power 100~240V AC, 50~60Hz
Dimensions 283 x 173 x 43mm (L x W x H)
Certification FCC Class A, CE
Warranty 1-year limited warranty

* Power savings may vary depending on products used. Maximum power saving up to 46% when compared with Airlink101 AGIGA8SW.

* Actual throughput will vary. Specifications are subject to change without notice. All products and trademarks are the property of their respective owners. Photos of product may not reflect actual content. Copyright 2011 Airlink101
